多路閥主要技術參數：Nominal Flow Rating；Operating Pressure(max.)；Back Pressure(max.)；Fluid Temperature；Viscosity；Ambient Temperature
多路閥主要技術參數：
|
Nominal Flow Rating |
45 l/min |
12 us gpm |
|
|
Operating Pressure(max.) |
315 bar |
4600 psi |
|
|
Back Pressure(max.) |
on outlet port |
25 bar |
360 psi |
|
Fluid Temperature |
with nbr seals |
-20°c ~ 80°c |
-4°f ~ 176°f |
|
with fpm seals |
-20°c ~ 100°c |
-4°f ~ 212°f |
|
|
Viscosity |
operating range |
15mm2 /s ~ 75mm2 /s |
15 ~ 75 cst |
|
max. |
400mm2 /s |
400 cst |
|
|
min. |
12mm2 /s |
12 cst |
|
|
Ambient Temperature |
-40°c ~ 60°c |
-40°f ~ 140°f |
|
